HWA38020372 Hobbywing XR10 Justock G3S Sensored Brushless ESC/SD G2.1 Motor Combo (17.5T)

Combo Overview: The Hobbywing XR10 Justock G3S Sensored Brushless ESC/SD G2.1 Motor Combo has been designed with...
Vendor: Hobbywing
Availability: Out Of Stock
Product Type: ESC & Motor Combo
$149.99
$149.99
Subtotal: $149.99
10 customers are viewing this product

Free Shipping

Free standard shipping on orders over $250

Free Returns

Learn More.

Built And Shipped Within 5 - 7 Bussiness Days

HWA38020372 Hobbywing XR10 Justock G3S Sensored Brushless ESC/SD G2.1 Motor Combo (17.5T)

HWA38020372 Hobbywing XR10 Justock G3S Sensored Brushless ESC/SD G2.1 Motor Combo (17.5T)

$149.99

HWA38020372 Hobbywing XR10 Justock G3S Sensored Brushless ESC/SD G2.1 Motor Combo (17.5T)

$149.99

Combo Overview:

The Hobbywing XR10 Justock G3S Sensored Brushless ESC/SD G2.1 Motor Combo has been designed with fixed, 0°, timing for spec class racing. The included SD G2.1 motor is an ideal stock motor for both 1/10 and 1/12 on and off-road racing. These two components paired together make for an ideal choice for beginners and experts alike.


Note: This product photo may not fully depict the described item. For comprehensive details on the listed product, please refer to the specifications provided.

Features:

  • ESC:
    • Built-in polarity protection. The XR10 Justock has integrated MOSFET's that if the battery terminals are connected in reverse, the MOSFET will be reverse-biased and will not allow current to flow through the system
    • Programmable via OTA Wireless module or 3in1 program box
    • Built-in capacitor module eliminates the need for external capacitors and unwanted space
    • RPM speed limit function supports up to 6 different speed, RPM, selections to meet the needs and demands of various competitions in the world (Set through OTA module or 3in1 box)
    • Internal ESC timing has been set to 0 degrees and cannot be adjusted for stock racing
    • Built-in BEC can support a maximum output current of up to 8A. Output voltage can be set between 6V or 7.4V
    • Calibration or performing a factory-reset can be achieved by using this SET button. Simple and easy to use
    • Supports both CCW (counterclockwise) and CW (clockwise) motor directions
    • Protection functions include: reverse polarity, battery voltage, ESC temperature, motor temperature, signal lost and locked rotor protection
    • ESC includes the Freewheeling setting allowing for lower ESC temps enhancing drivability through corners
    • Built-in data logging for post-run reports
  • Motor:
    • Use of a heat-resistant magnet attached aluminum case and double insulated windings, high precision bearings, and rotor with a strong structure guarantees outstanding performance and super durability
    • Built-in Hall sensor non-adjustable end bell combined with a high precision and balanced rotor guarantees the user a smooth and linear power on demand
    • Silicon O-ring seal fitted between the end bell and stator helps to conduct inner heat to the motor case and prevent dust from entering the HALL sensor
    • Detachable structure design for daily cleaning and maintenance can effectively prolong the service life of this Justock motor and improve its operating efficiency
    • This Justock motor is applicable to various 1/10th, 1/12th on-road & off-road vehicles. It can be an ideal choice for Stock or Sport class races but can also be a nice choice for newbies for practice
    • The motor design is in compliance with IFMAR, and ROAR specifications

Specifications:

  • ESC:
    • Continuous Current: 60A
    • Burst Current: 380A
    • Battery: 2S Lipo (Only 2S)
    • Built-in BEC: 6V/7.4V @ 4A(Switch-mode)
    • ESC programming: Independent programming port
    • Motor Supported: Sensor and sensorless brushless motor
    • Motor Limit: 10.5T, or greater,3650 Motor
    • Application: 1/10, 1/12 On-road and Off-road
    • Cooling Fan: Powered by BEC
    • Size: 40.9x33.9x32.1mm (LxWxH)
    • Weight: 75.4g (Including weight of wire)
    • ROAR Approval: Yes
  • Motor:
    • Scale: 1/10, 1/12
    • Brushless: Yes
    • Sensored: Yes
    • Pole Count: 2
    • KV Rating: 2050kV
    • LiPo Cells: 2-3S
    • No-Load Current(A): 3A
    • Outer Diameter: 35.9mm (1.413")
    • Length: 52.5mm (2.067")
    • Shaft Diameter: 3.17mm (0.125")
    • Weight: 176g (6.21oz)
    • Timing: Fixed

Includes:

  • (1) Justock G3SS ESC
  • (1) Justock 17.5T G2.1 brushless motor
  • (1) 5V cooling fan
  • (1) Sensor cable
